Max. machining dia.: 16mm
Max. headstock stoke: 130mm
Max. drilling dia.: 8mm
Max. threading dia.: M6xP = 1.0
Main spindle speed: 300 - 8000 rpm
Main spindle speed change: S4 digit direct commands (step less)
Direction of rotation: forward and reverse
Number of tools: 5 (tool post) = 3 (3 spindle end working attachment
Tool sizes: 10 x (80~120)
Rapid Traverse: Headstock - 12000mm/min, Tool post: 10000mm/min
Cutting federate: 1 - 6000 mm/min
Coolant tank cap.: Approx. 60 lts
Hydraulic tank cap.: 20lts
Direction of operation: Right hand
Height of spindle: 1100mm
No. of controlled axis: 4
Simultaneously controlled axis: 3
Coordinate command method: X Y Z absolute / U V W incremental
Max. Command value: +/- 9999.999 mm
Tape memory edit function: Tape length approx. 20m
Number of programs: 63
